Motion Capturing and Visualization laboratory

Motion capturing system

• Hardware: Three Oqus 3-camera series and one infrared Qqus 3- camera (Qualisys motion capture cameras) with high speed video. CMOS sensors 1280 * 1024 pixels. Maximum frame rate at full resolution and Field-Of-View (FOV) = 500 fps. Maximum frame rate at full resolution and reduced FOV = 10 000 fps. One extra set of three Oqus 3 high speed video cameras and one infrared Oqus 3 camera available on request, according to cooperation agreements with Faculty of Health Education and Social Work (AHS) at HiST. http://qualisys.iweb.se/archive/product_information_pdf/PI_Oqus.pdf
• One Wand and L-shape calibration set for Qualisys system calibration. Passive markers to be attached to the test persons.
• Three AVT Marlin F080B (b/w) Digital Video Cameras:
  Digital interface: 1394a FireWire IIDC. Picture size: 640x480 (VGA) x 30 fps, Resolution depth: 8-bit greyscale.
  http://www.alliedvisiontec.com

Computer

• Dual core processors, Intel Core 2 Duo E6600 2.4 GHz, med 4 MB cache. FourPCI-e busses
• Hard disk: 2 * 10 000 rpm in RAID-5.
• Graphic card. ASUS GeForce 7600 GS (nVidia) 2 GB RAM (PC2-6400) http://no.asus.com/products.aspx?l1=2&l2=6&l3=271&l4=0&model=1090&modelmenu=1

Software

• Qualisys Track Manager (QTM). All 2D and 3D data can be exported from QTM to different formats such as TSV, C3D and directly to Matlab.  http://www.qualisys.com/default.asp?viewset=1&on='Products'&id=&initid=48&heading=Products&mainpage=templates/Q02.asp?sida=40

• Own produced software for camera system calibration, image capturing, motion capturing/particle tracking and visualization
• 3D Studio Max 9
• Blender

Sound

• Surround system: Logitech Z-5450  http://www.komplett.no/k/ki.aspx?sku=315196

3D-Visualization

• Projector: Two professional projectors, F1+ SXGA+, resolution 1400 * 1050. Up to 4200 lumens. Produced by ProjectionDesign. Ultra Wide Angle lenses 1 : 1.The projectors are mounted in a special Constructed Frame produced by Cyviz for 3D-visualization and equipped with polarization filters. The projector rack is portable. Total weight of the rack with two projectors and synchronization/converter unit is ca 13 Kg.
• Screens: Two front projection screens. One Da-Lite Cinema Contour, size 3.00 m * 2.25 m http://www.da-lite.com/products/product.php?cID=20&pID=234 and one portable Steward FilmScreen with size 2.13 m * 1.53 m. One portable back projection screen, Stewart Film Screen, size 2.20 m * 1.65 m. http://www.stewartfilmscreen.com/Silver3D.html

Room
The laboratory expands ca. 50 m² andis situated at the 1. floor. Entrance is possible by wheel chair. The height to the ceiling varies between ca 1.5 m to ca 4 m. With respect to full size, human motion capturing, the lab is best suited for movements that can take place within a limited volume.
